Name: Onyx SC D1
SKU: 17287
Availability: OutOfStock

Onyx SC D1

$785.00 – $1,074.00

READY FOR ROWDY

The little brother to the Onyx DC, this is the Onyx SC D1. At 180mm of travel, this is our top of the line enduro race fork. Featuring the proven D1 damper, high/low speed compression, rebound, and externally adjustable OTT. With 36mm stanchions and our stiffest chassis yet, charge hard into the roughest sections with confidence.

Six clicks of low speed compression give quick access to firming up the fork for pedaling, opening up for descending, and mid settings for everything in between. Over thirty clicks of High Speed Compression give precise control for support on big hits. Shim stack controlled rebound that is 100% dynamic. meaning, the rebound is controlled based on the speed at which oil flows through the system. The fork will react to what you throw at it and be ready for what’s next. Our industry exclusive OTT feature really sets DVO product apart from anything else. It allows you to perfectly fine tune how the initial stroke feels without any mid/end stoke compromise. You really do the best of both worlds.

Combining the stiff chassis characteristics with our exclusive features and damping design give our forks a unique ride feel unlike anything else on the market.

HIGHLIGHTS
IN THE BOX

D1 Damper
Compression Bladder
OTT Off the Top Adjuster
Shim Stack Controlled Damping

Fender Kit
Suspension Set Up Guide
DVO Decal

SPECS

Adjustments:

High/Low Speed Compression | Rebound | OTT

Travel Range:

160-180mm

Starting Weight:

27.5 – 2200g. | 29 -2250g.

Offset:

27.5 – 42mm | 29 -44mm

Axle To Crown

27.5 – 575mm | 29 -592mm

Measurements at max travels

Stanchions:

36mm Tapered Alloy

Wheel Size:

27.5 | 29

Axle

15mm Bolted- Boost Spacing

Brake Mounting

Direct Mount 180mm

Color Options:

Black

RESOURCES

Videos

COMPRESSION BLADDER

At the heart of the damper is our compression bladder. An industry exclusive feature that surrounds a bladder with a large volume of oil and compresses it throughout the entire stroke. This provides unrivaled small bump sensitivity, durability, and damping consistency for long rides in rough conditions.

• No stiction
• Large oil volume
• Consistent Damping
• Extremely Durable
• Unique Ride Characteristics

YOUR HANDS WILL THANK YOU.

Our industry exclusive OTT feature really sets DVO product apart from anything else. It allows you to perfectly fine tune how the initial stroke feels without any mid/end stoke compromise. You really do get the best of both worlds.

The OTT feature works by using a 5mm allen key to externally add or remove preload on a coil negative spring. Once you’re about 30% of the way through the travel, the OTT spring is completely disengaged and you get into the positive air spring which controls your mid-stroke and bottom out. Set your air pressure for how you want the fork to feel in the mid to end stroke and fine tune your small bump sensitivity with the OTT feature.

INTEGRATED FENDER

For a clean and polished look that both functions and looks killer. A fully integrated fender comes with your fork for those sloppy days on the mountain!
